    High Precision Woodworking Edge Banding Machine Automatic Edge Bander

    Ask Lasest Price
    Model Number : SYS-368
    Brand Name : OSETMAC
    Certification : CE,ISO
    Price : Negotiable
    Delivery Time : 15 days
    Payment Terms : T/T, L/C
    Supply Ability : 3000 sets per year
    • Product Details
    • Company Profile

    High Precision Woodworking Edge Banding Machine Automatic Edge Bander

    SYS-368 Automatic Edge Bander with Trimming for Panel Furniture and PVC


    Product Description


    1. Ideal for straight edge banding on solid wood, MDF, particle board, etc, edge banding tapes can be solid wood, PVC, melamine, and veneer.

    2. Best quality and durable motor and electrical panels.

    3. Funcions ,voltage and others can be customized.

    4. High precision, high efficiency.


    Applications:


    This edge banding machine is suitable for PVC, ABS, MDF, Solid, shaving board, Melamine, Batten, Veneer ,plywood and particle board etc.


    Specifications:


    MODELSYS-368
    Panel Thickness10-60mm
    Edge Band Thickness0.4-3mm
    Panel Width≥60mm
    Panel Length≥150mm
    Feeding Speed15-23m/min
    Working Pressure0.6Mpa
    Voltage380V/50HZ/3PH
    Gluing Motor0.75KW 50HZ 1400RPM
    End Cutting Motor0.37KW * 2 200HZ 12000RPM
    Trimming Motor0.75KW * 4 300HZ 18000RPM
    Buffing Motor0.37KW * 2 50HZ 1400RPM
    Conveyor Motor2.2KW
    Lifting Motor0.25KW
    Glue Pot Heating Power1.85KW
    Assistant Heating Power0.45KW
    Lighting Power0.08KW
    Total Power10.4KW
    Dimension4417x830x1610mm
    Net Weight1500KGS

    Competitive Advantage:

    1. We can customize the outlook and functions of the machine according to your requirement.
    2. We have two wholly-owned manufacturing factories and can make sure of the delivery time.
